Image plot with a color scale

simage (generic function) draws an image (a grid of colored rectangles) and (optionally) adds a legend strip with the color scale (calls splot and image).

Usage

simage(x, ...)

# Default S3 method
simage(
  x = seq(0, 1, len = nrow(s)),
  y = seq(0, 1, len = ncol(s)),
  s,
  slim = range(s, finite = TRUE),
  col = jet.colors(128),
  breaks = NULL,
  legend = TRUE,
  horizontal = FALSE,
  legend.shrink = 1,
  legend.width = 1.2,
  legend.mar = ifelse(horizontal, 3.1, 5.1),
  legend.lab = NULL,
  bigplot = NULL,
  smallplot = NULL,
  lab.breaks = NULL,
  axis.args = NULL,
  legend.args = NULL,
  reset = TRUE,
  xlab = NULL,
  ylab = NULL,
  asp = NA,
  ...
)

Arguments

x: grid values for x coordinate. If x is a list, its components x$x and x$y are used for x and y, respectively. For compatibility with image, if the list has component z this is used for s.
...: additional graphical parameters (to be passed to image or simage.default; e.g. xlim, ylim, ...). NOTE: graphical arguments passed here will only have impact on the main plot. To change the graphical defaults for the legend use the par function beforehand (e.g. par(cex.lab = 2) to increase colorbar labels).
y: grid values for y coordinate.
s: matrix containing the values to be used for coloring the rectangles (NAs are allowed). Note that x can be used instead of s for convenience.
slim: limits used to set up the color scale.
col: color table used to set up the color scale (see image for details).
breaks: (optional) numeric vector with the breakpoints for the color scale: must have one more breakpoint than col and be in increasing order.
legend: logical; if TRUE (default), the plotting region is splitted into two parts, drawing the image plot in one and the legend with the color scale in the other. If FALSE only the image plot is drawn and the arguments related to the legend are ignored (splot is not called).
horizontal: logical; if FALSE (default) legend will appear on the right side. If TRUE the legend will be along the bottom.
legend.shrink: amount to shrink the size of legend relative to the full height or width of the plot.
legend.width: width in characters of the legend strip. Default is 1.2, a little bigger that the width of a character.
legend.mar: width in characters of legend margin that has the axis. Default is 5.1 for a vertical legend and 3.1 for a horizontal legend.
legend.lab: label for the axis of the color legend. Default is no label as this is usual evident from the plot title.
bigplot: plot coordinates for main plot. If not passed these will be determined within the function.
smallplot: plot coordinates for legend strip. If not passed these will be determined within the function.
lab.breaks: if breaks are supplied these are text string labels to put at each break value. This is intended to label axis on a transformed scale such as logs.
axis.args: additional arguments for the axis function used to create the legend axis (see image.plot for details).
legend.args: arguments for a complete specification of the legend label. This is in the form of list and is just passed to the mtext function. Usually this will not be needed (see image.plot for details).
reset: logical; if FALSE the plotting region (par("plt")) will not be reset to make it possible to add more features to the plot (e.g. using functions such as points or lines). If TRUE (default) the plot parameters will be reset to the values before entering the function.
xlab: label for the x axis.
ylab: label for the y axis.
asp: the y/x aspect ratio, see plot.window.

Value

Invisibly returns a list with the following 3 components:

bigplot: plot coordinates of the main plot. These values may be useful for drawing a plot without the legend that is the same size as the plots with legends.
smallplot: plot coordinates of the secondary plot (legend strip).
old.par: previous graphical parameters (par(old.par) will reset plot parameters to the values before entering the function).

Side Effects

If reset = TRUE, the plotting region ([par]("plt")) may be changed after exiting, to make it possible to add more features to the plot (setting reset = FALSE prevents this).

Author

Modified by Ruben Fernandez-Casal rubenfcasal@gmail.com.

Examples

# Regularly spaced 2D data
nx <- c(40, 40) # ndata =  prod(nx)
x1 <- seq(-1, 1, length.out = nx[1])
x2 <- seq(-1, 1, length.out = nx[2])
trend <- outer(x1, x2, function(x,y) x^2 - y^2)
simage( x1, x2, trend, main = 'Trend')
